Diamondback Interbike Booth

Interbike VTSB
YouTube Preview Image

Jon Kennedy from Diamonback shows us the Mason, Mission Pro, production Mason FS, Sortie Black 29er and the Scapegoat. The Mason features a slack 66½° headtube angle, 140mm Fox fork, sloping top tube, and is available as a complete bike and frame only. The Mission Pro has X9, X0 drivetrain, Race Face carbon crankset, Easton wheels, and is geared to the all mountain rider. The Sortie Black 29er is available in 4 trims and features a sloping top tube, is based off the 26″ Sortie platform, and is perfect for the trail/xc rider. The Scapegoat, based off the Mission platform, has the same geometry but adds an extra inch on the front of the fork. The light freeride bike features Knuckle Box technology, single sided hardware, and Easton wheelset, bar stem post.

YouTube Preview Image

Eric Porter introduces us to the new Diamondback Mason FS 29er that’s currently in production. He’s been testing riding the Mason FS since last November. The 29er all-mountain bike is based on Mason platform and features 140mm travel front and back, short chainstays, low bottom bracket for cornering and a 68° degree head angle.

Diamondback Interbike Booth Gallery
1
of
×

Diamondback Mason FS OEM

The in-production 29er all-mountain bike is based on Mason platform and features 140mm travel front and back, short chainstays, low bottom bracket for cornering and a 68° degree head angle.
×

Diamondback Mason FS 140mm 29er with Eric Porter

Eric Porter test riding the in-production Mason FS.
×

Diamondback Mason FS Tapered Headtube

The in-production 29er all-mountain bike is based on Mason platform and features 140mm travel front and back, short chainstays, low bottom bracket for cornering and a 68° degree head angle.
×

Diamondback Mason FS dropout

The in-production 29er all-mountain bike is based on Mason platform and features 140mm travel front and back, short chainstays, low bottom bracket for cornering and a 68° degree head angle.
×

Diamondback Knuckle Box

The Knuckle Box, or bell crank, is the core of our single-pivot four-bar suspension platform. Optimally placed pivots equate to a low leverage ratio, and ultimately to superior pedaling efficiency and small-bump compliance.
×

Diamondback Mason

Enter the Mason All Mountain hardtail. This rig is slack and low slung – meant for today’s shredder who wants to pedal up but charge down with aggressiveness. The Mason features an All Mountain 6061-T6 Weapons Grade Aluminum frame with a formed top tube, a formed and butted down tube, a tapered head tube, ISCG 05 tabs and a 142×12mm Maxle drop out. A 140mm travel Fox 34 TALAS 29 CTD air fork features external rebound, a butted alloy 1.5” Tapered steerer, 34mm Easton aluminum stanchions with magnesium lowers, and a QR15 thru axle. This also lends to a slack, 66.5 degree head angle. Combine this with short, 426mm/ 16.77? long chain stays and you can clearly see where this is going. This keeps the bike maneuverable, easy to manipulate in downhill and aired out sections, and easier to get the front end of the bike up with the slack head angle.
×

Diamondback Mason tapered headtube

Enter the Mason All Mountain hardtail. This rig is slack and low slung – meant for today’s shredder who wants to pedal up but charge down with aggressiveness. The Mason features an All Mountain 6061-T6 Weapons Grade Aluminum frame with a formed top tube, a formed and butted down tube, a tapered head tube, ISCG 05 tabs and a 142×12mm Maxle drop out. A 140mm travel Fox 34 TALAS 29 CTD air fork features external rebound, a butted alloy 1.5” Tapered steerer, 34mm Easton aluminum stanchions with magnesium lowers, and a QR15 thru axle. This also lends to a slack, 66.5 degree head angle. Combine this with short, 426mm/ 16.77? long chain stays and you can clearly see where this is going. This keeps the bike maneuverable, easy to manipulate in downhill and aired out sections, and easier to get the front end of the bike up with the slack head angle.
×

Diamondback Mason dropout

Enter the Mason All Mountain hardtail. This rig is slack and low slung – meant for today’s shredder who wants to pedal up but charge down with aggressiveness. The Mason features an All Mountain 6061-T6 Weapons Grade Aluminum frame with a formed top tube, a formed and butted down tube, a tapered head tube, ISCG 05 tabs and a 142×12mm Maxle drop out. A 140mm travel Fox 34 TALAS 29 CTD air fork features external rebound, a butted alloy 1.5” Tapered steerer, 34mm Easton aluminum stanchions with magnesium lowers, and a QR15 thru axle. This also lends to a slack, 66.5 degree head angle. Combine this with short, 426mm/ 16.77? long chain stays and you can clearly see where this is going. This keeps the bike maneuverable, easy to manipulate in downhill and aired out sections, and easier to get the front end of the bike up with the slack head angle.
×

Diamondback Mason Direct Mount Front Derailleur and Chain Guide

Enter the Mason All Mountain hardtail. This rig is slack and low slung – meant for today’s shredder who wants to pedal up but charge down with aggressiveness. The Mason features an All Mountain 6061-T6 Weapons Grade Aluminum frame with a formed top tube, a formed and butted down tube, a tapered head tube, ISCG 05 tabs and a 142×12mm Maxle drop out. A 140mm travel Fox 34 TALAS 29 CTD air fork features external rebound, a butted alloy 1.5” Tapered steerer, 34mm Easton aluminum stanchions with magnesium lowers, and a QR15 thru axle. This also lends to a slack, 66.5 degree head angle. Combine this with short, 426mm/ 16.77? long chain stays and you can clearly see where this is going. This keeps the bike maneuverable, easy to manipulate in downhill and aired out sections, and easier to get the front end of the bike up with the slack head angle.
×

Diamondback Mission Pro

With 6 inches of front and rear travel, the 2013 Mission series caters to the all mountain/Enduro riders. Super D’s and single track, up and down… the Mission continues to be the go-to steed for almost any situation. The 2013 Mission All Mountain 6" frame is created from 6061-T6 Weapons Grade Aluminum and features a hydroformed top tube, a butted and formed downtube seatstays, seatstay bridge, a tapered headtube, ISCG 05 tabs, a 142×12mm E-Thru Axle drop out and Diamondbacks legendary Knuckle Box Suspension technology.
×

Diamondback Scapegoat

ant the stability and ruggedness of a downhill bike with the agility and playfulness of an all mountain machine? Look no further that the Diamondback Scapegoat. The 2013 Scapegoat shares many of the pedal-efficient characteristics of the Diamondback Mission series and adds extra travel and reinforcement for a burly rip down the line of your choice. The 2013 Scapegoat 6" frame is created from 6061-T6 Weapons Grade Aluminum and features a hydroformed top tube, a butted and formed downtube seatstays, seatstay bridge, a tapered headtube, ISCG 05 tabs, a 142×12mm E-Thru Axle drop out and Diamondbacks legendary Knuckle Box Suspension technology.
×

Diamondback Scapegoat Tapered Headtube

×

Diamondback Scapegoat dropout

×

Diamondback Scapegoat linkage

×

Diamondback Outdoor Demo Booth
