X-Fusion Interbike Booth

Interbike Sponsored post
YouTube Preview Image

John Hauer discusses the new products for 2013 including the Slant RL2 34mm for 650B and 26″ and the brand new Trace RL2 with Uni-Crown 29er forks, the Microlite RL rear shock and the superlight Hilo SL seatpost that weighs in at 450g and has 125mm of adjustment.

X-Fusion Interbike Booth Gallery
1
of
×

X-Fusion Trace RL2 with Uni-Crown

The Trace series is the big-wheeled platform in our brand new 34mm chassis line. Developed to accompany the new progression of 29er bikes with longer travel and aggressive angles, the Trace offers a stout chassis with smooth and efficient damping. The RL2 damper will eat away the small bumps while the mid-valve provides unprecedented mid to ending stroke support. Also offered in the Trace line is the unique new Uni-Crown CSU (crown-steerer unit). Uni-Crown is a single piece crown steerer that increases chassis strength at that junction by over 50%! With the Trace's progressive new-school damping and light and stout chassis, riders will no longer have shy away from the most technical bits of trail but will be looking for what they can conquer next. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Uni-Crown Option
  • XC/Trail/AM/END
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered, Uni-Crown
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 29"
  • Colors: White / Black
  • Axle to Crown: 546mm @ 140mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion TraceRL2 with Uni-Crown

The Trace series is the big-wheeled platform in our brand new 34mm chassis line. Developed to accompany the new progression of 29er bikes with longer travel and aggressive angles, the Trace offers a stout chassis with smooth and efficient damping. The RL2 damper will eat away the small bumps while the mid-valve provides unprecedented mid to ending stroke support. Also offered in the Trace line is the unique new Uni-Crown CSU (crown-steerer unit). Uni-Crown is a single piece crown steerer that increases chassis strength at that junction by over 50%! With the Trace's progressive new-school damping and light and stout chassis, riders will no longer have shy away from the most technical bits of trail but will be looking for what they can conquer next. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Uni-Crown Option
  • XC/Trail/AM/END
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered, Uni-Crown
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 29"
  • Colors: White / Black
  • Axle to Crown: 546mm @ 140mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Trace RL2 with Uni-Crown

The Trace series is the big-wheeled platform in our brand new 34mm chassis line. Developed to accompany the new progression of 29er bikes with longer travel and aggressive angles, the Trace offers a stout chassis with smooth and efficient damping. The RL2 damper will eat away the small bumps while the mid-valve provides unprecedented mid to ending stroke support. Also offered in the Trace line is the unique new Uni-Crown CSU (crown-steerer unit). Uni-Crown is a single piece crown steerer that increases chassis strength at that junction by over 50%! With the Trace's progressive new-school damping and light and stout chassis, riders will no longer have shy away from the most technical bits of trail but will be looking for what they can conquer next. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Uni-Crown Option
  • XC/Trail/AM/END
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered, Uni-Crown
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 29"
  • Colors: White / Black
  • Axle to Crown: 546mm @ 140mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Trace RL2

The Trace series is the big-wheeled platform in our brand new 34mm chassis line. Developed to accompany the new progression of 29er bikes with longer travel and aggressive angles, the Trace offers a stout chassis with smooth and efficient damping. The RL2 damper will eat away the small bumps while the mid-valve provides unprecedented mid to ending stroke support. Also offered in the Trace line is the unique new Uni-Crown CSU (crown-steerer unit). Uni-Crown is a single piece crown steerer that increases chassis strength at that junction by over 50%! With the Trace's progressive new-school damping and light and stout chassis, riders will no longer have shy away from the most technical bits of trail but will be looking for what they can conquer next. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Uni-Crown Option
  • XC/Trail/AM/END
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered, Uni-Crown
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 29"
  • Colors: White / Black
  • Axle to Crown: 546mm @ 140mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Slant RL2

The Slant series was developed to bridge the gap between lightweight trail forks and high performance all-mountain forks. At X-Fusion we have taken note that not only suspension products have been progressing over the last few years, but the rider has as well. You all are fitter, faster, stronger and are looking for a product to match. The 34mm stanchion tube chassis provides the perfect balance between weight and strength in the trail and all-mountain category. The Slant comes equipped with our most efficient RL2 damper systems in a svelte, but stout chassis allowing you to dominate the trail in any direction. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Trail/AM/END
Specifications
  • Travel: 160mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: White / Black
  • Axle to Crown: 545mm @ 160mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Slant RL2

The Slant series was developed to bridge the gap between lightweight trail forks and high performance all-mountain forks. At X-Fusion we have taken note that not only suspension products have been progressing over the last few years, but the rider has as well. You all are fitter, faster, stronger and are looking for a product to match. The 34mm stanchion tube chassis provides the perfect balance between weight and strength in the trail and all-mountain category. The Slant comes equipped with our most efficient RL2 damper systems in a svelte, but stout chassis allowing you to dominate the trail in any direction. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Trail/AM/END
Specifications
  • Travel: 160mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: White / Black
  • Axle to Crown: 545mm @ 160mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Slant RL2

The Slant series was developed to bridge the gap between lightweight trail forks and high performance all-mountain forks. At X-Fusion we have taken note that not only suspension products have been progressing over the last few years, but the rider has as well. You all are fitter, faster, stronger and are looking for a product to match. The 34mm stanchion tube chassis provides the perfect balance between weight and strength in the trail and all-mountain category. The Slant comes equipped with our most efficient RL2 damper systems in a svelte, but stout chassis allowing you to dominate the trail in any direction. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Trail/AM/END
Specifications
  • Travel: 160mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: White / Black
  • Axle to Crown: 545mm @ 160mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Slant RL2

The Slant series was developed to bridge the gap between lightweight trail forks and high performance all-mountain forks. At X-Fusion we have taken note that not only suspension products have been progressing over the last few years, but the rider has as well. You all are fitter, faster, stronger and are looking for a product to match. The 34mm stanchion tube chassis provides the perfect balance between weight and strength in the trail and all-mountain category. The Slant comes equipped with our most efficient RL2 damper systems in a svelte, but stout chassis allowing you to dominate the trail in any direction. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series 15mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brake housing guide
  • Trail/AM/END
Specifications
  • Travel: 160mm
  • WT. LBS: (APR) 4.2 (15mm axle, 1 1/8th Steerer)
  • WT. Grams: 1905 (15mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 34mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: White / Black
  • Axle to Crown: 545mm @ 160mm
  • Max Rotor Size: 203mm
Technology
  • RL2, BHG, Lockout, Gold Slick Ano, X Series Axle
×

X-Fusion Microlite RL

The Microlite rear shock offers efficiency, simplicity and weight savings in the most compact package. Getting our top of the line Gold Slick Ano coating and weighing in at only 170 grams, the Microlite offers top performance at the least possible weight. For riders that like to keep the gram count low and the ride supple, the Microlite is the shock of choice. Features
  • New seal designs and materials optimize performance and increase durability.
  • Semi-progressive air-spring compression ratio for a maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Gold Slick Ano
  • XC
Specifications
  • Sizes: 165/38, 190/51
  • Weight: 170 grams (165mm)
  • Spring: Air
  • Adjustments: Air Pressure, Rebound, Lockout
  • Options: 5 piece hardware
Technology
  • Lockout, Gold Slick Ano
×

X-Fusion Microlite RL

The Microlite rear shock offers efficiency, simplicity and weight savings in the most compact package. Getting our top of the line Gold Slick Ano coating and weighing in at only 170 grams, the Microlite offers top performance at the least possible weight. For riders that like to keep the gram count low and the ride supple, the Microlite is the shock of choice. Features
  • New seal designs and materials optimize performance and increase durability.
  • Semi-progressive air-spring compression ratio for a maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Gold Slick Ano
  • XC
Specifications
  • Sizes: 165/38, 190/51
  • Weight: 170 grams (165mm)
  • Spring: Air
  • Adjustments: Air Pressure, Rebound, Lockout
  • Options: 5 piece hardware
Technology
  • Lockout, Gold Slick Ano
×

X-Fusion Microlite RL

The Microlite rear shock offers efficiency, simplicity and weight savings in the most compact package. Getting our top of the line Gold Slick Ano coating and weighing in at only 170 grams, the Microlite offers top performance at the least possible weight. For riders that like to keep the gram count low and the ride supple, the Microlite is the shock of choice. Features
  • New seal designs and materials optimize performance and increase durability.
  • Semi-progressive air-spring compression ratio for a maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Gold Slick Ano
  • XC
Specifications
  • Sizes: 165/38, 190/51
  • Weight: 170 grams (165mm)
  • Spring: Air
  • Adjustments: Air Pressure, Rebound, Lockout
  • Options: 5 piece hardware
Technology
  • Lockout, Gold Slick Ano
×

X-Fusion Hilo SL

Remember riding your bike before clip-less pedals? Before suspension even existed? How about before disc brakes? Would you want to go back to any of that? Well that's how everybody feels about adjustable seat posts. The ability to raise and lower your seat on the fly not only allows for the best possible performance but also offers extra safety while riding. Being able to drop your seat before a technical decent could be the difference between cleaning the section or picking your teeth out of the dirt. For 2013 we launch our brand new HILO SL that weighs in under 100 grams less than the current design. With 3 models now available there is an adjustable height seatpost option for every rider. Features
  • Hydraulic design allows for smooth and infinite adjustability
  • Aluminum shaft for weight savings
  • Gold Slick Ano shaft
  • New 2 bolt head design for weight savings
  • Double key-way design prevents lateral twisting
  • Passes CEN testing for fatigue and impact
  • Wide range of angle adjust on the seat post head
  • 100 gram + weight saving over steel shaft models
  • XC/Trail/AM/END/FR
Specifications
  • Travel: 125mm
  • Weight: 450 grams (30.9 No Cable)
  • OD: 30.9 / 31.6 mm
  • Adjustments: Seat Post Angle Adjustable, Infinitive Travel Adjustable, Remote Lever
  • Colors: Black with GSA
  • Length: 422mm
  • Insertion Depth: 217mm
×

X-Fusion Hilo SL

Remember riding your bike before clip-less pedals? Before suspension even existed? How about before disc brakes? Would you want to go back to any of that? Well that's how everybody feels about adjustable seat posts. The ability to raise and lower your seat on the fly not only allows for the best possible performance but also offers extra safety while riding. Being able to drop your seat before a technical decent could be the difference between cleaning the section or picking your teeth out of the dirt. For 2013 we launch our brand new HILO SL that weighs in under 100 grams less than the current design. With 3 models now available there is an adjustable height seatpost option for every rider. Features
  • Hydraulic design allows for smooth and infinite adjustability
  • Aluminum shaft for weight savings
  • Gold Slick Ano shaft
  • New 2 bolt head design for weight savings
  • Double key-way design prevents lateral twisting
  • Passes CEN testing for fatigue and impact
  • Wide range of angle adjust on the seat post head
  • 100 gram + weight saving over steel shaft models
  • XC/Trail/AM/END/FR
Specifications
  • Travel: 125mm
  • Weight: 450 grams (30.9 No Cable)
  • OD: 30.9 / 31.6 mm
  • Adjustments: Seat Post Angle Adjustable, Infinitive Travel Adjustable, Remote Lever
  • Colors: Black with GSA
  • Length: 422mm
  • Insertion Depth: 217mm
×

X-Fusion Hilo SL

Remember riding your bike before clip-less pedals? Before suspension even existed? How about before disc brakes? Would you want to go back to any of that? Well that's how everybody feels about adjustable seat posts. The ability to raise and lower your seat on the fly not only allows for the best possible performance but also offers extra safety while riding. Being able to drop your seat before a technical decent could be the difference between cleaning the section or picking your teeth out of the dirt. For 2013 we launch our brand new HILO SL that weighs in under 100 grams less than the current design. With 3 models now available there is an adjustable height seatpost option for every rider. Features
  • Hydraulic design allows for smooth and infinite adjustability
  • Aluminum shaft for weight savings
  • Gold Slick Ano shaft
  • New 2 bolt head design for weight savings
  • Double key-way design prevents lateral twisting
  • Passes CEN testing for fatigue and impact
  • Wide range of angle adjust on the seat post head
  • 100 gram + weight saving over steel shaft models
  • XC/Trail/AM/END/FR
Specifications
  • Travel: 125mm
  • Weight: 450 grams (30.9 No Cable)
  • OD: 30.9 / 31.6 mm
  • Adjustments: Seat Post Angle Adjustable, Infinitive Travel Adjustable, Remote Lever
  • Colors: Black with GSA
  • Length: 422mm
  • Insertion Depth: 217mm
×

X-Fusion Vector Air HLR

At a svelte 430 gram weight, the Vector Air provides the highest level of descending performance at the lightest possible weight. It's been specially designed to provide maximum heat dispersion, with an oversize damping body and pistons, as well as reduced air canister wall thickness, ensuring that even under the most extreme use, the rider has consistent performance. Despite being designed and engineered to tackle the most grueling descents, the Vector Air's light chassis allows for diverse applications. Unprecedented performance and marketability, the Vector Air is the most adjustable air shock on the market. Tuning capabilities of the Vector Air will allow riders in multiple product categories on a wide range of bikes to maximize their suspension performance. Features
  • 430 gram weight (half the weight of a coil shock)
  • Lighter than all competition's DH specific air shocks
  • Same features and benefits as race-winning Vector HLR coil
  • Oversized CNC-machined aluminum 31.5mm damper body for consistent damping.
  • Bored, reduced air canister wall thickness provided 40% greater cooling surface
  • Gold Slick Ano
  • AM/FR/DH
Specifications
  • Sizes: 200/57, 215/63 , 222/69, 240/76
  • Weight: 430 grams (240 x 76)
  • Spring: Air
  • Adjustments: Air Pressure, Reservoir Pressure, Rebound, Bottom-Out Adjust, High & Low Speed Compression
Technology
  • HLR, BPA, RVA, Gold Slick Ano
×

X-Fusion Vector Air HLR

The premier coil shock line by X-Fusion, the Vector Series provides ultimate fine tune adjustment, durability and performance while having the ability to tackle the harshest terrain. On top of it's industry leading performance, the sleek look of the all black body and compact design for maximum frame clearance has made the Vector Series one of the best looking shocks available. Highlighted by the Vector HLR, the shock used by our elite downhill athletes will help you in tackling the gnarliest DH tracks or provide a buttery smooth ride on your local trails. The Vector Series shocks are ready to take what you can dish! Features
  • CVS (Check Valve System) technology added for compression and rebound isolation ensuring the most consistent damping with improved adjustment ranges.
  • HLR damping system provides total damping control with external rebound adjustment and high-low speed compression adjustment. Compression and Rebound adjustments are isolated from affecting one another via CVS.
  • Refined compression circuits for more efficient and smoother energy absorption.
  • Sized eyelet bushings providing a smoother and more consistent mounting system.
  • Custom Tuning Available
  • AM/FR/DH
Specifications
  • Sizes: 200/57, 215/63 , 222/69, 240/76
  • Weight: 425 gram (240 x 76 without coil)
  • Spring: Steel Coil
  • Adjustments: Reservoir Pressure, Rebound, Bottom-Out Adjust, High & Low Speed Compression, Preload
Technology
  • HLR, BPA, Preload Adjustment, CVS. RVA
×

X-Fusion Vengeance HLR

The Vengeance Series excels when it comes to riding big mountain epics or rallying down the rockiest single tracks. This package offers Formula One level performance to aggressive riders who desire to conquer the entire mountain. For 2013 the Vengeance receives our brand new Gold Slick Ano stanchion treatment to ensure riders the smoothest, supplest ride on the market. With 170mm of travel, an internal travel-adjust system, two damper options (HLR and RC) and three spring systems (Air, Coil, DLA), there is a Vengeance option for everybody. It¹s just up to you to decide which one will be guiding you around the mountain. Features
  • The HLR damper is a twin-tube, cartridge based damper which features high and low speed, independently adjustable compression and rebound damping adjustment.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Gold Slick Ano stanchion treatment
  • X-Series 20mm tool-less axle system by Syntace
  • Brand new air-spring system for a consistent linear spring feel.
  • Brake housing guides
  • AM/FR/END
Specifications
  • Travel: 170mm
  • WT. LBS: (APR)5.3(170mm)
  • WT. Grams: 2254 (170mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Rebound, High & Low Speed Compression
  • Stanchion: 36mm, Gold Slick Ano Aluminum
  • Casting: Magnesium
  • Axle: X-20 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: Black, White
  • Axle to Crown: 565mm @ 170mm
  • Max Rotor Size: 203m
Technology
  • HLR, X Series Axle, Adjustment Shield, ITA, BHG, Gold Slick Ano
×

X-Fusion Vengeance HLR

The Vengeance Series excels when it comes to riding big mountain epics or rallying down the rockiest single tracks. This package offers Formula One level performance to aggressive riders who desire to conquer the entire mountain. For 2013 the Vengeance receives our brand new Gold Slick Ano stanchion treatment to ensure riders the smoothest, supplest ride on the market. With 170mm of travel, an internal travel-adjust system, two damper options (HLR and RC) and three spring systems (Air, Coil, DLA), there is a Vengeance option for everybody. It¹s just up to you to decide which one will be guiding you around the mountain. Features
  • The HLR damper is a twin-tube, cartridge based damper which features high and low speed, independently adjustable compression and rebound damping adjustment.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Gold Slick Ano stanchion treatment
  • X-Series 20mm tool-less axle system by Syntace
  • Brand new air-spring system for a consistent linear spring feel.
  • Brake housing guides
  • AM/FR/END
Specifications
  • Travel: 170mm
  • WT. LBS: (APR)5.3(170mm)
  • WT. Grams: 2254 (170mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Rebound, High & Low Speed Compression
  • Stanchion: 36mm, Gold Slick Ano Aluminum
  • Casting: Magnesium
  • Axle: X-20 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: Black, White
  • Axle to Crown: 565mm @ 170mm
  • Max Rotor Size: 203m
Technology
  • HLR, X Series Axle, Adjustment Shield, ITA, BHG, Gold Slick Ano
×

X-Fusion Vengeance HLR

The Vengeance Series excels when it comes to riding big mountain epics or rallying down the rockiest single tracks. This package offers Formula One level performance to aggressive riders who desire to conquer the entire mountain. For 2013 the Vengeance receives our brand new Gold Slick Ano stanchion treatment to ensure riders the smoothest, supplest ride on the market. With 170mm of travel, an internal travel-adjust system, two damper options (HLR and RC) and three spring systems (Air, Coil, DLA), there is a Vengeance option for everybody. It¹s just up to you to decide which one will be guiding you around the mountain. Features
  • The HLR damper is a twin-tube, cartridge based damper which features high and low speed, independently adjustable compression and rebound damping adjustment.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Gold Slick Ano stanchion treatment
  • X-Series 20mm tool-less axle system by Syntace
  • Brand new air-spring system for a consistent linear spring feel.
  • Brake housing guides
  • AM/FR/END
Specifications
  • Travel: 170mm
  • WT. LBS: (APR)5.3(170mm)
  • WT. Grams: 2254 (170mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Rebound, High & Low Speed Compression
  • Stanchion: 36mm, Gold Slick Ano Aluminum
  • Casting: Magnesium
  • Axle: X-20 tool-less axle
  • Wheel: 26", 27.5" (650b)
  • Colors: Black, White
  • Axle to Crown: 565mm @ 170mm
  • Max Rotor Size: 203m
Technology
  • HLR, X Series Axle, Adjustment Shield, ITA, BHG, Gold Slick Ano
×

X-Fusion Vengeance HLR DLA

The Vengeance Series excels when it comes to riding big mountain epics or rallying down the rockiest single tracks. This package offers Formula One level performance to aggressive riders who desire to conquer the entire mountain. For 2013 the Vengeance receives our brand new Gold Slick Ano stanchion treatment to ensure riders the smoothest, supplest ride on the market. With 170mm of travel, an internal travel-adjust system, two damper options (HLR and RC) and three spring systems (Air, Coil, DLA), there is a Vengeance option for everybody. It's just up to you to decide which one will be guiding you around the mountain. Features The HLR damper is a twin-tube, cartridge based damper which features high and low speed, independently adjustable compression and rebound damping adjustment.
  • DLA (Down Low Adjust) for on the fly travel reduction.
  • X-Series 20mm tool-less axle system by Syntace
  • Gold Slick Ano stanchion treatment
  • Brand new air-spring system for a consistent linear spring feel.
  • Brake housing guides
Specifications
  • Travel: 170mm/140mm
  • WT. LBS: (APR)5.5(170mm)
  • WT. Grams: 2494 (170mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Rebound, High and Low Speed Compression, DLA
  • Stanchion: 36mm, Gold Slick Ano, Aluminum
  • Casting: Magnesium
  • Axle: X-20 tool-less axle
  • Wheel: 26², 27.5² (650b)
  • Colors: Black, White
  • Axle to Crown: 565mm @ 170mm
  • Max Rotor Size: 203mm
Technology HLR, X Series Axle, Adjustment Shield, DLA, BHG, Gold Slick Ano
×

X-Fusion Slide RL2

The younger taller brother of the Velvet is born to bring a performance level XC fork at a cost effective price to the 29'er market. The Slide 29's 120mm of extremely controlled travel comes within it¹s lightweight chassis and offers an on the fly lockout switch for maximum efficiency. Whether you need a reliable race fork or are out exploring the back-country, the slide promises to deliver a smooth, consistent ride for as long as your legs will keep spinning. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guides provided on all fork models.
  • XC/Trail
Specifications
  • Travel: 120mm
  • WT. LBS: (APR) 4.0 (100mm)
  • WT. Grams: 1814 (100mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Lockout, Rebound
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 29"
  • Colors: Black, White
  • Axle to Crown: 526mm @ 120mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Slide RL2

The younger taller brother of the Velvet is born to bring a performance level XC fork at a cost effective price to the 29'er market. The Slide 29's 120mm of extremely controlled travel comes within it¹s lightweight chassis and offers an on the fly lockout switch for maximum efficiency. Whether you need a reliable race fork or are out exploring the back-country, the slide promises to deliver a smooth, consistent ride for as long as your legs will keep spinning. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guides provided on all fork models.
  • XC/Trail
Specifications
  • Travel: 120mm
  • WT. LBS: (APR) 4.0 (100mm)
  • WT. Grams: 1814 (100mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Lockout, Rebound
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 29"
  • Colors: Black, White
  • Axle to Crown: 526mm @ 120mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Slide RL2

The younger taller brother of the Velvet is born to bring a performance level XC fork at a cost effective price to the 29'er market. The Slide 29's 120mm of extremely controlled travel comes within it¹s lightweight chassis and offers an on the fly lockout switch for maximum efficiency. Whether you need a reliable race fork or are out exploring the back-country, the slide promises to deliver a smooth, consistent ride for as long as your legs will keep spinning. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guides provided on all fork models.
  • XC/Trail
Specifications
  • Travel: 120mm
  • WT. LBS: (APR) 4.0 (100mm)
  • WT. Grams: 1814 (100mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Lockout, Rebound
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 29"
  • Colors: Black, White
  • Axle to Crown: 526mm @ 120mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Slide RL2

The younger taller brother of the Velvet is born to bring a performance level XC fork at a cost effective price to the 29'er market. The Slide 29's 120mm of extremely controlled travel comes within it¹s lightweight chassis and offers an on the fly lockout switch for maximum efficiency. Whether you need a reliable race fork or are out exploring the back-country, the slide promises to deliver a smooth, consistent ride for as long as your legs will keep spinning. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guides provided on all fork models.
  • XC/Trail
Specifications
  • Travel: 120mm
  • WT. LBS: (APR) 4.0 (100mm)
  • WT. Grams: 1814 (100mm)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Air, Lockout, Rebound
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 29"
  • Colors: Black, White
  • Axle to Crown: 526mm @ 120mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Velvet RL2

The Velvet series is our 32mm chassis XC and Trail Fork. Having 140mm's of travel, remote or lever actuated lockout, and the option of our DLA travel adjust system, the Velvet is prepared to go for as long as your legs can keep spinning those gears. In addition to the performance features, the Velvet is offered in multiple steerer tube configurations and with either our X-15 tool-less axle system or industry standard 9mm. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series tool-less axle system by Syntace
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guide
  • Internally converted to 650b fork using an internal travel spacer.
  • XC/Trail
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 3.8 (9mm axle, 1 1/8th Steerer)
  • WT. Grams: 1723 (9mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 26" (27.5" 650b Convertible)
  • Colors: White / Black
  • Axle to Crown: 519mm @140mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Velvet RL2

The Velvet series is our 32mm chassis XC and Trail Fork. Having 140mm's of travel, remote or lever actuated lockout, and the option of our DLA travel adjust system, the Velvet is prepared to go for as long as your legs can keep spinning those gears. In addition to the performance features, the Velvet is offered in multiple steerer tube configurations and with either our X-15 tool-less axle system or industry standard 9mm. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series tool-less axle system by Syntace
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guide
  • Internally converted to 650b fork using an internal travel spacer.
  • XC/Trail
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 3.8 (9mm axle, 1 1/8th Steerer)
  • WT. Grams: 1723 (9mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 26" (27.5" 650b Convertible)
  • Colors: White / Black
  • Axle to Crown: 519mm @140mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Velvet RL2

The Velvet series is our 32mm chassis XC and Trail Fork. Having 140mm¹s of travel, remote or lever actuated lockout, and the option of our DLA travel adjust system, the Velvet is prepared to go for as long as your legs can keep spinning those gears. In addition to the performance features, the Velvet is offered in multiple steerer tube configurations and with either our X-15 tool-less axle system or industry standard 9mm. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series tool-less axle system by Syntace
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guide
  • Internally converted to 650b fork using an internal travel spacer.
  • XC/Trail
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 3.8 (9mm axle, 1 1/8th Steerer)
  • WT. Grams: 1723 (9mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 26" (27.5" 650b Convertible)
  • Colors: White / Black
  • Axle to Crown: 519mm @140mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion Velvet RL2

The Velvet series is our 32mm chassis XC and Trail Fork. Having 140mm's of travel, remote or lever actuated lockout, and the option of our DLA travel adjust system, the Velvet is prepared to go for as long as your legs can keep spinning those gears. In addition to the performance features, the Velvet is offered in multiple steerer tube configurations and with either our X-15 tool-less axle system or industry standard 9mm. Features
  • The RL2 damper has rebound damping adjustment and uses an on-off switch for lockout.
  • X-Series tool-less axle system by Syntace
  • Internal travel adjust is offered within all of our forks using a push-pin ladder system on the air-spring rod. Travel spacers can be used in some cases for even more custom travel settings.
  • Brake housing guide
  • Internally converted to 650b fork using an internal travel spacer.
  • XC/Trail
Specifications
  • Travel: 140mm
  • WT. LBS: (APR) 3.8 (9mm axle, 1 1/8th Steerer)
  • WT. Grams: 1723 (9mm axle, 1 1/8th Steerer)
  • Spring: Air
  • Steerer: 1 1/8, Tapered
  • Adjustments: Lockout, Rebound, Air
  • Stanchion: 32mm, Aluminum
  • Casting: Magnesium
  • Axle: X-15 tool-less axle, 9mm
  • Wheel: 26" (27.5" 650b Convertible)
  • Colors: White / Black
  • Axle to Crown: 519mm @140mm
  • Max Rotor Size: 180mm
Technology
  • RL2, Lockout, X Series Axle, BHG, ITA
×

X-Fusion O2 RCX

The O2 Series continues to progress as one of the best performing, most reliable air shocks on the market. For 2013, the O2 Series has had both the compression and rebound tunes updated for a suppler, more efficient ride. With multiple adjustment configuration options there is an O2 model for every rider. Pick between multiple stage compression adjustment, on the fly lockout, or even a handle bar remote lockout to pin-point the right shock for your specific needs. Features
  • New seal designs and materials optimize performance and increase durability.
  • New air sleeve provides a lower air-spring compression ratio for a more linear
  • New compression and rebound tunes for better small bump sensitivity and maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Additional Volume (AV) air-sleeve option provides a more linear air-spring to match certain frame designs
  • XC/Trail/AM/END
Specifications
  • Sizes: 165/38, 190/51, 200/51 200/57, 215/63, 222/63, 240/76
  • Weight: 228 grams (165x38)
  • Spring: Air
  • Adjustments: 4 position Compression Adjustment, Rebound
Technology
  • High Flow Piston, AV Sleeve
×

X-Fusion O2 RCX

The O2 Series continues to progress as one of the best performing, most reliable air shocks on the market. For 2013, the O2 Series has had both the compression and rebound tunes updated for a suppler, more efficient ride. With multiple adjustment configuration options there is an O2 model for every rider. Pick between multiple stage compression adjustment, on the fly lockout, or even a handle bar remote lockout to pin-point the right shock for your specific needs. Features
  • New seal designs and materials optimize performance and increase durability.
  • New air sleeve provides a lower air-spring compression ratio for a more linear
  • New compression and rebound tunes for better small bump sensitivity and maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Additional Volume (AV) air-sleeve option provides a more linear air-spring to match certain frame designs
  • XC/Trail/AM/END
Specifications
  • Sizes: 165/38, 190/51, 200/51 200/57, 215/63, 222/63, 240/76
  • Weight: 228 grams (165x38)
  • Spring: Air
  • Adjustments: 4 position Compression Adjustment, Rebound
Technology
  • High Flow Piston, AV Sleeve
×

X-Fusion O2 RCX

The O2 Series continues to progress as one of the best performing, most reliable air shocks on the market. For 2013, the O2 Series has had both the compression and rebound tunes updated for a suppler, more efficient ride. With multiple adjustment configuration options there is an O2 model for every rider. Pick between multiple stage compression adjustment, on the fly lockout, or even a handle bar remote lockout to pin-point the right shock for your specific needs. Features
  • New seal designs and materials optimize performance and increase durability.
  • New air sleeve provides a lower air-spring compression ratio for a more linear
  • New compression and rebound tunes for better small bump sensitivity and maximum efficiency.
  • Optional 5-Piece mounting hardware system offers superior strength, reduced drag, and ensures longer bushing life.
  • Sized eyelet bushings ensure a smooth and consistent mounting system straight from the factory.
  • Additional Volume (AV) air-sleeve option provides a more linear air-spring to match certain frame designs
  • XC/Trail/AM/END
Specifications
  • Sizes: 165/38, 190/51, 200/51 200/57, 215/63, 222/63, 240/76
  • Weight: 228 grams (165x38)
  • Spring: Air
  • Adjustments: 4 position Compression Adjustment, Rebound
Technology
  • High Flow Piston, AV Sleeve
×

X-Fusion Vector HLR

The premier coil shock line by X-Fusion, the Vector Series provides ultimate fine tune adjustment, durability and performance while having the ability to tackle the harshest terrain. On top of it's industry leading performance, the sleek look of the all black body and compact design for maximum frame clearance has made the Vector Series one of the best looking shocks available. Highlighted by the Vector HLR, the shock used by our elite downhill athletes will help you in tackling the gnarliest DH tracks or provide a buttery smooth ride on your local trails. The Vector Series shocks are ready to take what you can dish! Features
  • CVS (Check Valve System) technology added for compression and rebound isolation ensuring the most consistent damping with improved adjustment ranges.
  • HLR damping system provides total damping control with external rebound adjustment and high-low speed compression adjustment. Compression and Rebound adjustments are isolated from affecting one another via CVS.
  • Refined compression circuits for more efficient and smoother energy absorption.
  • Sized eyelet bushings providing a smoother and more consistent mounting system.
  • Custom Tuning Available
  • AM/FR/DH
Specifications
  • Sizes: 200/57, 215/63 , 222/69, 240/76
  • Weight: 425 gram (240 x 76 without coil)
  • Spring: Steel Coil
  • Adjustments: Reservoir Pressure, Rebound, Bottom-Out Adjust, High & Low Speed Compression, Preload
Technology
  • HLR, BPA, Preload Adjustment, CVS. RVA
×

X-Fusion Vector HLR

The premier coil shock line by X-Fusion, the Vector Series provides ultimate fine tune adjustment, durability and performance while having the ability to tackle the harshest terrain. On top of it's industry leading performance, the sleek look of the all black body and compact design for maximum frame clearance has made the Vector Series one of the best looking shocks available. Highlighted by the Vector HLR, the shock used by our elite downhill athletes will help you in tackling the gnarliest DH tracks or provide a buttery smooth ride on your local trails. The Vector Series shocks are ready to take what you can dish! Features
  • CVS (Check Valve System) technology added for compression and rebound isolation ensuring the most consistent damping with improved adjustment ranges.
  • HLR damping system provides total damping control with external rebound adjustment and high-low speed compression adjustment. Compression and Rebound adjustments are isolated from affecting one another via CVS.
  • Refined compression circuits for more efficient and smoother energy absorption.
  • Sized eyelet bushings providing a smoother and more consistent mounting system.
  • Custom Tuning Available
  • AM/FR/DH
Specifications
  • Sizes: 200/57, 215/63 , 222/69, 240/76
  • Weight: 425 gram (240 x 76 without coil)
  • Spring: Steel Coil
  • Adjustments: Reservoir Pressure, Rebound, Bottom-Out Adjust, High & Low Speed Compression, Preload
Technology
  • HLR, BPA, Preload Adjustment, CVS. RVA
×

X-Fusion Vector HLR

The premier coil shock line by X-Fusion, the Vector Series provides ultimate fine tune adjustment, durability and performance while having the ability to tackle the harshest terrain. On top of it's industry leading performance, the sleek look of the all black body and compact design for maximum frame clearance has made the Vector Series one of the best looking shocks available. Highlighted by the Vector HLR, the shock used by our elite downhill athletes will help you in tackling the gnarliest DH tracks or provide a buttery smooth ride on your local trails. The Vector Series shocks are ready to take what you can dish! Features
  • CVS (Check Valve System) technology added for compression and rebound isolation ensuring the most consistent damping with improved adjustment ranges.
  • HLR damping system provides total damping control with external rebound adjustment and high-low speed compression adjustment. Compression and Rebound adjustments are isolated from affecting one another via CVS.
  • Refined compression circuits for more efficient and smoother energy absorption.
  • Sized eyelet bushings providing a smoother and more consistent mounting system.
  • Custom Tuning Available
  • AM/FR/DH
Specifications
  • Sizes: 200/57, 215/63 , 222/69, 240/76
  • Weight: 425 gram (240 x 76 without coil)
  • Spring: Steel Coil
  • Adjustments: Reservoir Pressure, Rebound, Bottom-Out Adjust, High & Low Speed Compression, Preload
Technology
  • HLR, BPA, Preload Adjustment, CVS. RVA
×

X-Fusion Interbike Booth

×

X-Fusion Interbike Booth

(Visited 11,457 times, 2 visits today)

NOTE: There are two ways to comment on our articles: Facebook or Wordpress. Facebook uses your real name and can be posted on your wall while Wordpress uses our login system. Feel free to use either one.

Facebook Comments:



Wordpress Comments:

Leave a Reply

Your email address will not be published. Required fields are marked *

*
*
